Home  Function module  Single Axis Robot  Single Axis Robot YTSC14 Series Lead Screw Drive Series·General Environment Type
  • Single Axis Robot YTSC14 Series Lead Screw Drive Series·General Environment Type

Single Axis Robot YTSC14 Series Lead Screw Drive Series·General Environment Type

Product Category: Single Axis Robot

Operational Environment: General environment

Operational Guides: Double Guide Rail

Repeated Positioning Accuracy: ±0.01

Series: Screw Drive Series

Transmission Mode: Trapezoidal Lead Screw

Transverse Allowable Moment: 124N.m

Width Of Base: 135

Detail
